The simplicity of urine sampling has been combined with the excellent sensing abilities of CRISPR to improve diagnostic testing for kidney transplant patients, an international research team reports in the journal Nature Biomedical Engineering.
Image Credit: Nathan Devery/Shutterstock.com
The new test screens for two common opportunistic viruses infecting kidney transplant patients, cytomegalovirus (CMV) and BK polyomavirus (BKV), and CXCL9 mRNA, whose expression increases during acute cellular kidney transplant rejection.
"Most people think of gene editing when they think of CRISPR, but this tool has great potential for other applications, especially cheaper and faster diagnostics," said Dr. Michael Kaminski, who heads the Kidney Cell Engineering and CRISPR Diagnostics Lab at the Max Delbrück Center for Molecular Medicine in the Helmholtz Association (MDC) and Charité - Universitätsmedizin Berlin.
He spearheaded the test's development while at the Collins lab at the Massachusetts Institute of Technology (MIT). Since 2020 Kaminski, who is a medical doctor at Charité's Medical Department, Division of Nephrology and Internal Intensive Care Medicine, started a new lab at the Berlin Institute for Molecular Systems Biology (BIMSB) from MDC.
Kidney transplant patients are on medications suppressing their immune systems to reduce the chance the organ will be rejected.
But this increases their risk of getting sick from infections. Closely monitoring patients for both infection and rejection is critical and guides the delicate balance of care. Usually, this is done via blood tests and kidney biopsies, which are time-consuming, more invasive and expensive.
While affordable urine-based diagnostic tests are available for a variety of biomarkers, from diabetes to pregnancy, they have not been widely adapted for nucleic acids, such as DNA or RNA. That is where CRISPR comes in.
CRISPR technology is able to find very small segments of a DNA or RNA sequence guided by a complimentary piece of RNA. It works in tandem with certain types of Cas proteins, which cut the target sequence, as well as a fluorescent reporter molecule.
This so-called collateral cleavage releases fluorescence, indicating the presence of a target. Many labs have been investigating CRISPR's diagnostic potential on synthetic material, but few have tested real clinical samples.
The challenge is getting down to concentrations that are clinically meaningful...It really makes a huge difference if you are aiming for a ton of synthetic target in your test tube, versus if you want to get to the single-molecule level in a patient fluid."
Positive or negative
The test kit, formally called an assay, uses a two-step process. First, viral target DNA in a urine sample must be amplified - copied enough times so CRISPR can detect it even if there is just one target molecule present.
The team used a specific CRISPR-Cas13 protocol known as SHERLOCK to optimize the process for viral DNA. The results are conveyed much like a home pregnancy test. When a paper strip is dipped in the prepared sample, if only one line appears on the strip, the result is negative, while two lines indicate a virus is present.
"It's exciting to see the results appear on the test strips," said Robert Greensmith, a first-year Ph.D. student in Kaminiski's Lab and paper co-author. "As someone new to working with CRISPR, I'm impressed by how it makes for such a robust testing platform."
For very low target concentrations, often a pale second line appears on the test strip, which could cause confusion. So, the team developed a smartphone app that unbiasedly analyzes pictures of the test strip and renders the final call based on the line's intensity.
The researchers used a similar process for the rejection marker CXCL9. There, mRNA was isolated and amplified, followed by CRISPR-Cas13 mediated target detection.
After a lot of work to optimize the technique, the researchers used their assay to analyze more than 100 samples from kidney transplant patients. The assay was very accurate even with low levels of BKV or CMV infection, and correctly detected signs of acute cellular transplant rejection.
While a patent application is pending, Kaminski, who is a medical doctor and clinical researcher, is interested in larger clinical studies comparing the assay to conventional monitoring methods. He would also like to investigate ways to make the test even more streamlined.
Right now, samples must be heated for preparation and the test requires multiple steps. While it could be used in a hospital setting, it's not quite ready for at-home testing.
The ultimate goal is a one-step process that can quantitatively measure multiple parameters. That way, patients can measure specific changes against their individual baselines.
Kaminski notes this test could also be useful for other immunocompromised people at risk for viral infections, while the CRISPR-based diagnostic approach could potentially be adapted for other organ transplants.
Kaminski, M.M., Alcantar, M.A., Lape, I.T. et al. A CRISPR-based assay for the detection of opportunistic infections post-transplantation and for the monitoring of transplant rejection. Nat Biomed Eng (2020). https://doi.org/10.1038/s41551-020-0546-5
